BENEFITS
- Pure sine wave output
- Wide DC input range
- User-adjustable charging current and voltage
- Smart battery charger design for optimized battery performance
- Monitoring software for real-time status display and control.
- Configurable AC/Solar input priority via LCD setting
- Parallel operation up to 9 units only for 3K/4K/5K models
Specification
| MODEL NUMBER | FA-OFFINVX-12V-1000VA | FA-OFFINV- 24V-1500VA |
FA-OFFINV- 24V-2000VA |
FA-OFFINV- 24V-3000VA |
FA-OFFINV- 24V-4000VA |
FA-OFFINV- 48V-5000VA |
FA-OFFINV- 48V-6000VA |
| RATED POWER | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W |
| INPUT | |||||||
| Voltage | 230 VAC | ||||||
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | ||||||
| Frequency Range | 50 Hz/60 Hz (Auto sensing) | ||||||
| OUTPUT | |||||||
| AC Voltage Regulation (Batt. Mode) |
230 VAC ± 5% | 230 VAC ± 10% | 230 VAC ± 5% | 230 VAC ± 10% | |||
| Surge Power | 2000VA | 3000VA | 4000A | 6000VA | 8000VA | 10000VA | 12000VA |
| Efficiency (Peak) | 90%~93% | ||||||
| Transfer Time | 15 ms (For Personal Computers) ; 20 ms (For Home Appliances) | ||||||
| Waveform | Pure sine wave | ||||||
| BATTERY | |||||||
| Battery Voltage | 12 VDC | 24 VDC | 24 VDC | 24 VDC | 48 VDC | 48 VDC | 48 VDC |
| Floating Charge Voltage | 13.5 VDC | 27 VDC | 27 VDC | 27 VDC | 54 VDC | 54 VDC | 54 VDC |
| Overcharge Protection | 16 VDC | 33 VDC | 31 VDC | 33 VDC | 60 VDC | 63 VDC | 63 VDC |
| SOLAR CHARGER & AC CHARGER | |||||||
| Solar Charger Type | MPPT | ||||||
| Max. PV Array Power | 600W | 2000W | 1200W | 2400 W | 6000 W | ||
| Max. PV Array Open Circuit Voltage |
400VDC | 400VDC | 400VDC | 500 VDC | 500 VDC | 500 VDC | 500 VDC |
| MPP Range @operating Voltage |
120 ~ 380 VDC | 120 ~ 450 VDC | |||||
| Max. Solar Charge Current | 50 A | 60 A | 50 A | 50A | 50A | 60A | 120 A |
| Max. AC Charge Current | 20 A | 40A | 25 A | 25 A | 60A | 60A | 100 A |
| Max. Charge Current | 50 A | 60 A | 57 A | 57 A | 110A | 120 A | 120 A |
| PHYSICAL | |||||||
| Dimension, D x W x H (mm) | 88 x 225x 320 | 100 x 280 x 390 | 88 x 225x 320 | 100 x 285 x 334 | 155 x 295 x 455 | 100 x 300 x 440 | |
| Net Weight (kgs) | 5.5 | 8.5 | 5.5 | 6.3 | 9.5 | 9 | 10 |
| Communication Interface | USB/RS232/RS485/Wifi/Dry-contact | ||||||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | ||||||
| Operating Temperature | -10°C to 50°C | ||||||
| Storage Temperature | -15°C to 60°C | ||||||
